Removal Procedure

WARNING: This page is about a different car, the 2002 Oldsmobile Aurora. However, it is still accessible from the selected car via links, so may be relevant.
  1. Open the rear compartment lid.
  2. Remove the push-in retainers securing the rear compartment lid trim (1) to the rear compartment lid.
  3. Remove the rear compartment lid trim (1) from the compartment lid.
    Fig 1: Removing Rear Compartment Lid Trim
    G01804024Courtesy of GENERAL MOTORS CORP.
