Removal Procedure

WARNING: This page is about a different car, the 2002 GMC Savana Special, 2002 GMC Savana Camper Special, 2002 GMC Savana, and 2002 Chevrolet Chevy Express. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the retainer at the top of the side front door weatherstrip.
  2. Remove the side front door weatherstrip from the top of the door. Use 3M Release Agent or the equivalent.
  3. Pull the side front door weatherstrip in order to remove the weatherstrip from the channel on the side of the door.
  4. Remove the side front door weatherstrip and the retainers from the bottom of the door.
  5. Clean the door of all of the old adhesive.
Fig 1: Removing Side Front Door Weatherstrip
G01737137Courtesy of GENERAL MOTORS CORP.
