Removal Procedure

WARNING: This page is about a different car, the 2002 Oldsmobile Aurora and 2001 Oldsmobile Aurora. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the rear console trim plate. Refer to Trim Plate Replacement - Console Rear  .
  2. Remove the two clips holding the pin (1) into the console.
  3. Remove the pin (1) in order to remove the door assembly.
    Fig 1: Locating Door Assembly Pin
    G01803127Courtesy of GENERAL MOTORS CORP.
