Removal Procedure

WARNING: This page is about a different car, the 2002 GMC Savana Special, 2002 GMC Savana Camper Special, 2002 GMC Savana, and 2002 Chevrolet Chevy Express. However, it is still accessible from the selected car via links, so may be relevant.
  1. Reach over the back of the bench seat and remove the child seat top tether from the top tether anchor (1).
  2. Remove the child seat.
  3. Remove the respective belt buckle bolt from the frame weld nut. Refer to Seat Belt Buckle Replacement - Rear (All Except Luxury)  or Seat Belt Buckle Replacement - Rear (Luxury (Y91))  .
  4. Remove the buckles.
    Fig 1: Removing Child Seat Top Tether
    G01737625Courtesy of GENERAL MOTORS CORP.
  5. Inspect the anchors, pivot points, belts, and buckles for damage, and replace if necessary
Fig 2: Inspecting Child Restraint Tether Anchor Components
G01737626Courtesy of GENERAL MOTORS CORP.
