Removal Procedure

WARNING: This page is about a different car, the 2002 GMC Savana Special, 2002 GMC Savana Camper Special, 2002 GMC Savana, and 2002 Chevrolet Chevy Express. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the screws (3) that retain the assist handle to the seatback (1).
  2. Remove the assist handle (2) from the seatback.
Fig 1: Removing Assist Handle - Front Passenger Side
G01737234Courtesy of GENERAL MOTORS CORP.
