Removal Procedure

WARNING: This page is about a different car, the 2002 GMC Savana Special, 2002 GMC Savana Camper Special, 2002 GMC Savana, and 2002 Chevrolet Chevy Express. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the inside door handle bezel. Refer to HANDLE BEZEL REPLACEMENT - INSIDE .
  2. Remove the screws that retain the right side rear door trim plates to the right side rear door.
  3. Remove the right side rear door trim plate from the right side rear door.
  4. Gently pull out the trim panel at the top of the window opening. Using a suitable and long flat-bladed tool, pry the retaining clips apart in order to disengage the clips.
  5. Lift the right side rear door trim panel up in order to release the tabs on the right side rear door trim panel.
  6. Remove the right side rear door trim panel from the door.
    Fig 1: Removing Trim Panel (Rear Door - Right)
    G01737388Courtesy of GENERAL MOTORS CORP.
