Removal Procedure

WARNING: This page is about a different car, the 2002 GMC Savana Special, 2002 GMC Savana Camper Special, 2002 GMC Savana, and 2002 Chevrolet Chevy Express. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the instrument panel passenger knee bolster. Refer to Knee Bolster Replacement - Right .
  2. Remove the fuel sender buffer module (2) from the instrument panel passenger knee bolster inner bracket (4).
  3. Disconnect the electrical connector (3) from the fuel sender buffer module.
  4. Remove the fuel sender buffer module from the vehicle.
    Fig 1: Removing Fuel Sender Buffer Module Components
    G01736556Courtesy of GENERAL MOTORS CORP.
