Installation Procedure

WARNING: This page is about a different car, the 2002 GMC Savana Special, 2002 GMC Savana Camper Special, 2002 GMC Savana, and 2002 Chevrolet Chevy Express. However, it is still accessible from the selected car via links, so may be relevant.
  1. Connect the electrical connector (2) to the engine coolant level indicator module.
  2. Install the engine coolant level indicator module (1) to the brake pedal support.
  3. Install the instrument panel driver knee bolster panel. Refer to Trim Panel Replacement - Knee Bolster .
    Fig 1: Connecting Electrical Connector & Installing Engine Coolant Level Indicator Module
    G01736553Courtesy of GENERAL MOTORS CORP.
