Removal Procedure

WARNING: This page is about a different car, the 2002 GMC Savana Special, 2002 GMC Savana Camper Special, 2002 GMC Savana, and 2002 Chevrolet Chevy Express. However, it is still accessible from the selected car via links, so may be relevant.
  1. Disconnect the electrical connector from the retractable underhood (UH) lamp.
  2. Remove the bolts (2) that retain the retractable underhood lamp to the hood.
  3. Remove the retractable underhood lamp (1) from the vehicle.
    Fig 1: Removing Bolts & Underhood Lamp
    G01736199Courtesy of GENERAL MOTORS CORP.
