Removal Procedure

WARNING: This page is about a different car, the 2002 Buick Regal and 2002 Buick Century. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the coolant recovery reservoir and move aside. Refer to COOLANT RECOVERY RESERVOIR REPLACEMENT in ENGINE COOLING .
    Fig 1: Coolant Recovery Reservoir
    G01720096Courtesy of GENERAL MOTORS CORP.
  2. Remove the accessory drive belt from the power steering pump pulley. Refer to SPECIFICATIONS & DRIVE BELT ROUTING .
  3. Remove the ignition control wiring harness near the power steering pump.
  4. Remove the power steering pressure hose from the power steering pump. Refer to Power Steering Pressure Hose Replacement (3.1L)  or Power Steering Pressure Hose Replacement (3.8L)  .
  5. Remove the power steering return hose from the power steering pump. Refer to Power Steering Return Hose Replacement (3.1L)  or Power Steering Return Hose Replacement (3.8L)  .
  6. Remove the power steering pump mounting bolts.
  7. Remove the power steering pump.
  8. Remove the power steering pump pulley from the power steering pump. Refer to Power Steering Pulley Replacement (3.8L)  or Power Steering Pulley Replacement (3.1L)  .
  9. Remove the power steering pump reservoir from the power steering pump. Refer to Power Steering Reservoir Replacement - Off Vehicle (CB Series) .
