Removal Procedure

WARNING: This page is about a different car, the 2002 Buick Regal and 2002 Buick Century. However, it is still accessible from the selected car via links, so may be relevant.
  1. Raise and support the vehicle.
  2. Remove the tires and wheels.
  3. Remove the left and right stabilizer shaft link nuts from the stabilizer shaft links (1).
    Fig 1: Removing/Installing Stabilizer Shaft Link Nuts
    G00370326Courtesy of GENERAL MOTORS CORP.
  4. Remove the insulator brackets (3) and the bolts from the stabilizer shaft (1).
    Fig 2: Removing/Installing Insulator Brackets & Bolts From Stabilizer Shaft
    G00379282Courtesy of GENERAL MOTORS CORP.
  5. Remove the stabilizer shaft (1) from the rear suspension support.
