Removal & Installation: Starter: Removal

WARNING: This page is about a different car, the 2002 Chevrolet Malibu. However, it is still accessible from the selected car via links, so may be relevant.

Disconnect the negative battery cable. Raise the vehicle. Remove the lower closeout panel.
Remove the electrical leads from starter. See Fig 1. Remove flywheel inspection shield.
Remove the starter motor-to-engine bolts, then lower the starter. Remove the starter. See Figure.

Fig 1: Identifying Starter Motor Electrical Leads

Courtesy of GENERAL MOTORS CORP.
