Removal Procedure

WARNING: This page is about a different car, the 2002 Oldsmobile Aurora. However, it is still accessible from the selected car via links, so may be relevant.
  1. Drain the engine oil. Refer to Engine Oil and Oil Filter Replacement .
  2. Disconnect the electrical connector from engine oil level switch.
  3. Remove the engine oil level switch from the oil pan.
    Fig 1: Removing Engine Oil Level Switch
    G01816958Courtesy of GENERAL MOTORS CORP.
