Speed Sensors: Installation

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2004 GMC Sierra, 2004 GMC Cab & Chassis Sierra, 2004 Chevrolet Silverado, 2004 Chevrolet Cab & Chassis Silverado, and 2003 GMC Sierra. However, it is still accessible from the selected car via links, so may be relevant.
NOTE: DO NOT rotate the sensor in its retaining bracket. Changing the sensor/bracket orientation may cause improper operation.
  1. Install a new a "O" ring (3) on the speed sensor (2). Lubricate the "O" ring with clean transmission fluid. See Figure .
  2. Install the new speed sensor (2) into the speed sensor bore. Align the hole in the retaining bracket with the bolt hole in the speed sensor boss.
  3. Install the speed sensor bolt and tighten to specification. See TORQUE SPECIFICATIONS  .
  4. Reconnect the external wiring harness to the speed sensor.
