Transmission Fluid Pressure Manual Valve Position Switch: Installation

WARNING: This page is about a different car, the 2003 Buick Regal and 2003 Buick Century. However, it is still accessible from the selected car via links, so may be relevant.
  1. Carefully install the fluid pressure manual valve position switch. Handle the switch carefully, the fluid pressure manual valve position switch is very delicate. See Fig 1 .
  2. Install the control valve body bolts (375, 379 and 381) that mount the fluid pressure manual valve position switch to the control valve body (300). Tighten control valve body bolts to specification. See TORQUE SPECIFICATIONS  .
  3. Connect the transaxle wiring harness.
  4. Install the case side cover. See REMOVAL & INSTALLATION in SERVICING - CENTURY & REGAL article.
Fig 1: Removing & Installing TFP Manual Valve Position Switch
G00073405Courtesy of GENERAL MOTORS CORP.
