Special Tools

WARNING: This page is about a different car, the 2009 Saturn Vue. However, it is still accessible from the selected car via links, so may be relevant.

Illustration	Tool Number/Description
Courtesy of GENERAL MOTORS CORP.	CH 47976 Active Fuel Injector Tester
Courtesy of GENERAL MOTORS CORP.	CH 48027-100 Digital Pressure Gage
Courtesy of GENERAL MOTORS CORP.	GE 41415-50 Tank Cap Adaptor
Courtesy of GENERAL MOTORS CORP.	J 23738-A Mityvac
Courtesy of GENERAL MOTORS CORP.	J 26792 HEI Spark Tester
Courtesy of GENERAL MOTORS CORP.	J 34730-405 Injector Test Lamp
Courtesy of GENERAL MOTORS CORP.	J 35555 (SA9180NE) Metal Mityvac
Courtesy of GENERAL MOTORS CORP.	J 35616-200 Test Light Probe Kit
Courtesy of GENERAL MOTORS CORP.	J 35616-C GM Approved Terminal Test Kit
Courtesy of GENERAL MOTORS CORP.	J 35800-A Fuel Injector Cleaner
Courtesy of GENERAL MOTORS CORP.	J 36850 Transjel Lubricant
Courtesy of GENERAL MOTORS CORP.	J 37088-A (SA9157-E) Fuel Line Disconnect Tool Set
Courtesy of GENERAL MOTORS CORP.	J 37287 Fuel Line Shut-Off Adaptors
Courtesy of GENERAL MOTORS CORP.	J 38522 Variable Signal Generator
Courtesy of GENERAL MOTORS CORP.	J 39021 Fuel Injector Coil and Balance Tester
Courtesy of GENERAL MOTORS CORP.	J 39021-210 Injector Tester Adaptor Box
Courtesy of GENERAL MOTORS CORP.	J 39021-450 Fuel Injector Harness Adaptor
Courtesy of GENERAL MOTORS CORP.	J 39194-B Heated Oxygen Sensor Wrench
Courtesy of GENERAL MOTORS CORP.	J 39194-C Oxygen Sensor Wrench
Courtesy of GENERAL MOTORS CORP.	J 41413 EVAP Pressure and Purge Station
Courtesy of GENERAL MOTORS CORP.	J 41413-200 (J 41413-100) Evaporative Emissions System Tester (EEST)
Courtesy of GENERAL MOTORS CORP.	J 41413-300 EVAP Cap and Plug Kit
Courtesy of GENERAL MOTORS CORP.	J 41413-VLV EVAP Port Vent Fitting Tool
Courtesy of GENERAL MOTORS CORP.	J 42873-1 3/8 Fuel Line Shut-Off Valve
Courtesy of GENERAL MOTORS CORP.	J 42873-2 5/16 Return Pipe Shut-Off Valve
Courtesy of GENERAL MOTORS CORP.	J 42960-2 Fuel Flapper Door Holder
Courtesy of GENERAL MOTORS CORP.	J 42964-1 3/8 Fuel Pipe Shut-Off Valve
Courtesy of GENERAL MOTORS CORP.	J 42964-2 5/16 Fuel Pipe Shut-Off Valve
Courtesy of GENERAL MOTORS CORP.	J 43244 Relay Puller Pliers
Courtesy of GENERAL MOTORS CORP.	J 44175 Fuel Composition Tester
Courtesy of GENERAL MOTORS CORP.	J 45004 Fuel Tank Drain Hose
Courtesy of GENERAL MOTORS CORP.	J 45722 Fuel Sender Lock Ring Wrench
