Rear Side Door Lock Striker Replacement

WARNING: This page is about a different car, the 2009 Saturn Vue. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Rear Side Door Striker

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
1	Rear Side Door Latch Striker Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 25 N.m (18 lb ft)
2	Rear Side Door Latch Striker Procedure Ensure the spacer is in place. Ensure proper alignment after installation. Refer to Rear Side Door Lock Striker Adjustment .

Callout

Component Name

Rear Side Door Latch Striker Bolt (Qty: 2)

CAUTION: Refer to Fastener Caution .

Tighten: 25 N.m (18 lb ft)

Rear Side Door Latch Striker

Procedure

Ensure the spacer is in place.
Ensure proper alignment after installation. Refer to Rear Side Door Lock Striker Adjustment .
