Liftgate Lower Molding Replacement
WARNING: This page is about a different car, the 2009 Saturn Vue. However, it is still accessible from the selected car via links, so may be relevant.
| Callout | Component Name |
|---|---|
| Preliminary Procedure: Open the rear liftgate in order to access the outer lower retainer nuts. |
|
| 1 | Liftgate Lower Molding Nut (Qty: 2)
CAUTION:
Refer to Fastener Caution
.
Tighten: 1.5 N.m (13 lb in) |
| 2 | Liftgate Lower Molding Retainer (Qty: 6) Tip: Ensure the gaskets are in place on the retainers prior to installing the molding to the vehicle. |
| 3 | Liftgate Lower Molding |
