Removal Procedure

WARNING: This page is about a different car, the 2007 Saturn Vue. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: View Of Intake Air Temperature (IAT) Sensor 2
    GM1233528Courtesy of GENERAL MOTORS CORP.
  1. Turn the ignition OFF.
  2. Disconnect the intake air temperature (IAT) sensor harness connector.
  3. Remove the IAT sensor from the side of the intake manifold (5).
