Installation Procedure

WARNING: This page is about a different car, the 2007 Saturn Vue. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: View Of Generator (L66)

Courtesy of GENERAL MOTORS CORP.

Install the air cleaner assembly into position, aligning locking pins into the front panel.

NOTE: Refer to Fastener Notice .

Install the air cleaner attachment bolt.
Tighten: Tighten the bolt to 10 N.m (89 lb in).

Fig 2: View Of Filter Element & Air Cleaner Assembly

Courtesy of GENERAL MOTORS CORP.

Install the filter element and air cleaner assembly top cover.

Fig 3: View Of Air Cleaner Element

Courtesy of GENERAL MOTORS CORP.

Tighten the clamp at the air cleaner assembly.
Tighten: Tighten the clamp to 4 N.m (35 lb in).
Connect the IAT 1 sensor connector.
