Special Tools

WARNING: This page is about a different car, the 2007 Saturn Vue. However, it is still accessible from the selected car via links, so may be relevant.

Special Tools

Illustration	Tool Number/Description
Courtesy of GENERAL MOTORS CORP.	J 7079-2 Universal Driver Handle - Non-Threaded
Courtesy of GENERAL MOTORS CORP.	J 8092 Driver Handle
Courtesy of GENERAL MOTORS CORP.	J 23907 Slide Hammer with Bearing Adapter
Courtesy of GENERAL MOTORS CORP.	J 24433 Pinion Cone and Side Bearing Installer
Courtesy of GENERAL MOTORS CORP.	J 35616 GM-Approved Terminal Test Kit
Courtesy of GENERAL MOTORS CORP.	J 36346 Fascia Retainer Remover
Courtesy of GENERAL MOTORS CORP.	J 36513 Gear and Bearing Separator Plate
Courtesy of GENERAL MOTORS CORP.	J 43405 Engine Support Fixture Adapter
Courtesy of GENERAL MOTORS CORP.	J 44015 Steering Linkage Installer
Courtesy of GENERAL MOTORS CORP.	J 44017 Stub Shaft Assembly Remover
Courtesy of GENERAL MOTORS CORP.	J 44375 Assembly Pallet
Courtesy of GENERAL MOTORS CORP.	J 44376 Bearing Pusher/Puller
Courtesy of GENERAL MOTORS CORP.	J 44377 Input Shaft Anti-Rotation Tool
Courtesy of GENERAL MOTORS CORP.	J 44378 Press Adapter - all shafts
Courtesy of GENERAL MOTORS CORP.	J 44379 Differential Bearing Puller Plate
Courtesy of GENERAL MOTORS CORP.	J 44380 Differential Bearing Race Puller
Courtesy of GENERAL MOTORS CORP.	J 44381 Shifter Bearing/Input and Output Bearing Remover
Courtesy of GENERAL MOTORS CORP.	J 44382 Countershaft Needle Bearing Puller
Courtesy of GENERAL MOTORS CORP.	J 44383 Countershaft Bearing Installer - to case
Courtesy of GENERAL MOTORS CORP.	J 44385 Differential Bearing Race and Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 44386 Input/Output Bearing Installer
Courtesy of GENERAL MOTORS CORP.	J 44387 Output Shaft Bearing Sleeve Installer and Pin
Courtesy of GENERAL MOTORS CORP.	J 44388 Final End Checking Fixture
Courtesy of GENERAL MOTORS CORP.	J 44389 Countershaft Bearing Installer
Courtesy of GENERAL MOTORS CORP.	J 45341 Rear Wheel Drive Shaft Removal Tool
Courtesy of GENERAL MOTORS CORP.	SA 9105E Engine Support Fixture - 3 Bar
Courtesy of GENERAL MOTORS CORP.	SA 91100C Tie Rod Separator
Courtesy of GENERAL MOTORS CORP.	SA 91112T Axle Seal Protector
Courtesy of GENERAL MOTORS CORP.	SA 9133T-1 Axle Seal Puller Adapter
Courtesy of GENERAL MOTORS CORP.	SA 9133T-2 Axle Seal Puller Adapter
Courtesy of GENERAL MOTORS CORP.	SA 9173G Slide Hammer
