Removal Procedure

WARNING: This page is about a different car, the 2007 Saturn Vue. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: View Of Rocker Panel Molding
    GM929252Courtesy of GENERAL MOTORS CORP.
  1. Remove the push-in retainers along the bottom of the rocker panel molding.
  2. Remove the push-in retainers from the front and rear wheelhouse liner to the rocker panel.
  3. Slide the rocker panel molding forward.
  4. Lift rocker panel molding outward at the top to remove from vehicle.
