Removal Procedure

WARNING: This page is about a different car, the 2007 Saturn Vue. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: Removing/Installing Cluster Trim Panel Screws
    GM937097Courtesy of GENERAL MOTORS CORP.
  1. Remove the cluster trim panel screws.
  2. Pull out to remove the cluster trim panel.
