Removal Procedure

WARNING: This page is about a different car, the 2003 Pontiac Aztek and 2003 Buick Rendezvous. However, it is still accessible from the selected car via links, so may be relevant.

Remove the air cleaner duct.
Drain the coolant until the coolant level is below the throttle body heater hoses. Refer to DRAINING AND FILLING COOLING SYSTEM .
Use the J 38185 in order to remove the hose clamp.
Remove the throttle body heater outlet hose.

Fig 1: Removing Air Cleaner Duct And Throttle Body Heater Outlet Hose

Courtesy of GENERAL MOTORS CORP.
