Removal Procedure

WARNING: This page is about a different car, the 2003 Saturn Vue. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: Liftgate Latch Striker
    GM928950Courtesy of GENERAL MOTORS CORP.
    CAUTION: When a lift gate hold open device is being removed or installed, provide alternate support to avoid the possibility of damage to the vehicle or personal injury.
  1. Open the lift gate and support.
  2. Remove the upper rear garnish molding. Refer to Garnish Molding Replacement - Rear Upper .
  3. Mark the location of the lift gate hinges with a grease pencil.
  4. Remove the lift gate struts. Refer to Strut Replacement - Liftgate
  5. Remove the hinge to lift gate bolts.
  6. Remove the hinge to body nuts.
  7. Remove the hinges.
