Removal Procedure

WARNING: This page is about a different car, the 2003 Saturn Vue. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the rear door window. Refer to Window Replacement - Rear Door .
  2. Remove the rear door applique. Refer to Door Frame Applique Replacement - Rear .
  3. Remove the rear door window weatherstrip run channel assembly. Refer to Window Weatherstrip Run Channel Assembly Replacement - Rear .
  4. Remove the rear door outer panel. Refer to Outer Door Panel Replacement Rear - Bolt On .
  5. Remove the rear door sound insulator. Refer to Sound Insulator Replacement - Rear Door .
    6. Fig 1: Rear Door Window Run Channel
    GM928787Courtesy of GENERAL MOTORS CORP.
  6. Remove the rear door window run channel and fixed glass assembly.
    • Remove the lower bolt from the fixed glass post.
    • Disengage the fixed glass post upper clip from the door frame by using a small screwdriver to press up on the clip.
    • Depress the mushroom retainers at the top ends of the metal glass run channels.
    • Remove the seal leg from the front metal glass run channel.
    • Starting from the front corner of the door, remove the seal from the door header flange.
    • Remove the seal and fixed glass assembly from the door.
