RPO Options
WARNING: This page is about a different car, the 2003 Saturn Vue. However, it is still accessible from the selected car via links, so may be relevant.
The entertainment system on this vehicle is configured with either a base or uplevel audio system. Both the base and uplevel audio systems contain a radio, antenna, and speakers.
The following shows the Entertainment RPO's that are available for this vehicle:
- (UQ4) Base Four Speaker
- (UW6) Uplevel Six Speaker
- (WBM) Premium Audio
(Includes amplifier and subwoofer for VUE; or amplifier and subwoofer rear speakers for ION)
Radio Features
| Controls | AM/FM Radio (UM7) | AM/FM CD Radio (U1C) | AM/FM Cassette/CD Radio (UP0) | AM/FM Cassette/6 Disc CD Radio (UR9) |
|---|---|---|---|---|
| Power | Push the VOL Knob | |||
| Volume | Rotate the VOL knob | |||
| Recall | Push the RCL button | |||
| Preset | Push station preset rocker buttons 1-6 | Push station present buttons 1-6 | ||
| Band | Press AM/FM | Press AM/FM. If listening to CD, will change function from CD to radio. | Press AM/FM. If listening to CD or tape, will change function from CD to radio. | |
| A. Set | Press and hold AM/FM button until tone is generated. The radio will automatically scan and preset the strongest stations. Press and hold until tone is generated to cancel. | |||
| Balance | Lightly pull out on VOL knob. Detent signifies center of balance. | Press MODE button until BAL is displayed, then use + or - button to adjust. | Press BASS/TREB/FAD/BAL knob until BAL is displayed. Rotate knob to desired setting. | |
| Fade | Rotate the FADE ring. Detent signifies center of balance. | Press MODE button until FAD is displayed, then use + or - button to adjust. | Press BASS/TREB/FAD/BAL knob until FAD is displayed. Rotate knob to desired setting. | |
| Bass | Press BASS/TREB knob to release. Rotate to change amount of bass in audio. | Press MODE button until BAS is displayed, then use + or - button to adjust. | Press BASS/TREB/FAD/BAL knob until BASS is displayed. Rotate knob to desired setting. | |
| Treble | Press BASS/TREB knob to release. Lightly pull outward. Rotate to change amount of treble in audio. | Press MODE button until TREB is displayed, then use + or - button to adjust. | Press BASS/TREB/FAD/BAL knob until TREB is displayed. Rotate knob to desired setting. | |
| Tune | TUNE/SEEK rocker manually increases or decreases frequency. | TUNE/SEEK rocker manually increases or decreases frequency. | TUNE/SEEK rocker manually increases or decreases frequency until the button is released. | |
| Seek | Hold TUNE/SEEK rocker until tone sounds. Radio will automatically increase or decrease frequency to next receivable station. | Momentarily press the TUNE/SEEK rocker to automatically increase or decrease frequency to next receivable station. | ||
| Scan | Press SCN button to automatically scan through all stations sequentially, pausing at each one for five seconds. | Press SCAN rocker button until tone is generated to automatically scan through, in either ascending or descending order, pausing at each receivable station. | ||
| Tone Control | - | - | Use either side of the AUTO TONE rocker to scroll through the preset tone options. | |
| Setting Clock |
|
|
||
Cassette Player Features
| Controls | AM/FM Radio (UM7) | AM/FM CD Radio (U1C) | AM/FM Cassette/CD Radio (UP0) | AM/FM Cassette/6 Disc CD Radio (UR9) |
|---|---|---|---|---|
| Change Modes | - | - | Press CD/TP button to change between CD and tape player. Operation only available if media is already loaded. | Press AUX button to change between CD and tape player. Operation only available if media is already loaded. |
| Play | - | - | Tape begins to automatically play when inserted, or when CD/TP button is used to select tape function. | Tape begins to automatically play when inserted, or when AUX button is used to select tape function. |
| Fast Forward | - | - | Press FF rocker button. Press again to stop fast forward and resume normal play. | |
| Rewind | - | - | Press REW rocker button. Press again to stop rewind and resume normal play. | |
| Eject | - | - | Press the EJ button. | |
| Repeat | - | - | Press the RPT button. | |
| Previous Song | - | - | Press PREV button once to rewind to beginning of current song. Press again to rewind to beginning of previous song. | |
| Next Song | - | - | Press the NEXT button to advance to beginning of next song on tape. | |
| Switch Sides | - | - | Press SIDE button. Display will also reflect change in direction. | |
| Dolby Noise Reduction | - | - | Press Dolby B Noise Reduction button to reduce tape hiss. | |
CD Player Features
| Controls | AM/FM Radio (UM7) | AM/FM CD Radio (U1C) | AM/FM Cassette/CD Radio (UP0) | AM/FM Cassette/6 Disc CD Radio (UR9) |
|---|---|---|---|---|
| Change Modes | - | Press CD button to change function from radio to CD. CD begins to play automatically. | Press CD/TP button to change between CD and tape player. Operation only available if media is already loaded. | Press AUX button to change between CD and tape player. Operation only available if media is already loaded. |
| Play CD | - | CD will automatically begin to play when one is inserted. | CD will automatically begin to play when one is loaded. | |
| Eject SINGLE CD | - | Press the EJ button. | Press the LD/EJ button. Then press the preset button when prompted to indicate which CD should ejected, or which slot should be loaded. | |
| Eject ALL CDs | - | - | - | Press and hold the LD/EJ button and all discs are ejected in order. "LOAD" is then displayed. |
| Previous Track | - | Press the PRV button. | Press the PRV button or DISC/SEEK/SCAN rocker button | Press PRV button |
| Next Track | - | Press the NXT button. | Press the NXT button or DISC/SEEK/SCAN rocker button | Press NXT button |
| Rewind | - | Press and hold REV button. | Press and hold REW button. | |
| Fast Forward | - | Press and hold FWD button. | Press and hold FF button. | |
| Random Track Order | - | Press the RDM button. Press again to cancel. | Press the RDM button. Press again to cancel. | Press the RDM button. Press again to cancel. Note that 3 modes are available: Random play on current disc, Random play on all discs, Random play cancelled. |
| Repeat | - | Press the RPT button to repeat the current track. Press again to cancel. | Press the RPT button to repeat the current disc. Press again to cancel. | |
| Load ALL CDs | - | - | - | Used when NO CDs are currently in radio. Discs are loaded one at a time, and the radio will display "WAIT" between each disc. |
| Previous Disc | - | - | - | Press left side of DISC/SEEK/SCAN button |
| Next Disc | - | - | - | Press right side of DISC/SEEK/SCAN button |
