Removal Procedure
WARNING: This page is about a different car, the 2002 Pontiac Grand Prix. However, it is still accessible from the selected car via links, so may be relevant.
- When replacing or repairing an emblem/nameplate do the following:
- 1.1. Use tape to protect the mounting surface during removal.
- 1.2. Use tape for alignment marks for installation of the emblem/nameplate.
- To remove an emblem/nameplate, heat the emblem/nameplate using J 25070.
- Hold the J 25070 approximately 152 mm (6 in) from the surface.
- Apply heat using a circular motion for about 30 seconds.
NOTE: Refer to EXTERIOR TRIM EMBLEM REMOVAL NOTICE .
- Use a plastic, flat-bladed tool to lift or remove the emblem/nameplate from the panel surface.IMPORTANT: If tape is still intact on the molding or panel, do not remove the tape. Clean the tape and the mating surface with adhesive cleaner. Wipe the tape and the mating surface with a clean, lint free cloth. If the tape is damaged, continue with the replacement procedure.
- Apply the adhesive foam tape to the back of the emblem/nameplate and press the emblem/nameplate in place.
- When replacing, remove all adhesive as follows:
- For body panels, use a 3MTM Scotch Brite molding adhesive remover disk 3MTM P/N 07501 or equivalent.
- For plastic panels, use a lint free cloth and Varnish Makers and Painters (VMP) naphtha or a 50/50 mixture by volume of isopropyl alcohol and water to remove the adhesive.
