Test Description

WARNING: This page is about a different car, the 2002 Pontiac Grand Prix. However, it is still accessible from the selected car via links, so may be relevant.

The numbers below refer to the step numbers on the diagnostic table.

  1. 5. This step tests to see if there is a short to voltage in the seat belt indicator supply voltage circuit
  2. 7. This step tests to see if there is an open, high resistance, or a short to ground in the seat belt indicator supply voltage circuit
    Fig 1: DTC 001
    G01617646Courtesy of GENERAL MOTORS CORP.
