Installation Procedure

WARNING: This page is about a different car, the 2003 Buick Regal and 2003 Buick Century. However, it is still accessible from the selected car via links, so may be relevant.
  1. Engage the push-in retainers in order to install the quarter lower trim.
    2. Fig 1: Installing Quarter Lower Trim Panel
    G01588494Courtesy of GENERAL MOTORS CORP.
  2. Install the door weatherstrip.
  3. Install the rear seat back. Refer to SEAT BACK REPLACEMENT - REAR (NON-FOLDING) or SEAT BACK REPLACEMENT - REAR (FOLDING) in Seats.
  4. Install the rear seat cushion. Refer to SEAT CUSHION REPLACEMENT - REAR in Seats.
  5. Install the rear carpet retainer. Refer to CARPET RETAINER REPLACEMENT - REAR  .
