Removal Procedure

WARNING: This page is about a different car, the 2002 Oldsmobile Bravada, 2002 GMC Envoy XL, 2002 GMC Envoy, and 2002 Chevrolet TrailBlazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Open the liftgate window.
  2. Remove the screws that retain the liftgate applique.
  3. Close the liftgate window.

    Important:  Do not open the liftgate with the liftgate glass open.

  4. Close the liftgate window and open the liftgate.
  5. Remove the liftgate applique from the liftgate pinch-weld flange.
    Fig 1: Removing Liftgate Applique From Liftgate Pinch-Weld Flange
    G01719021Courtesy of GENERAL MOTORS CORP.
