Removal Procedure

WARNING: This page is about a different car, the 2003 GMC Sierra, 2003 GMC Cab & Chassis Sierra, 2003 Chevrolet Silverado, and 2003 Chevrolet Cab & Chassis Silverado. However, it is still accessible from the selected car via links, so may be relevant.
CAUTION: If the passenger seat cushion foam is damaged when you remove the heater element, replace the passenger presence system in order to prevent personal Injury.
  1. Remove the seat trim panel. Refer to Trim Panel Replacement-Front Seat   .
  2. Remove the seat cushion trim cover. Refer to Seat Cushion Trim Cover And Pad Replacement   .
  3. Peel the seat cushion heater off of the pad.
  4. Disconnect the seat cushion heater wiring harness.
    Fig 1: Front Seat Cushion Heater Element
    G01579262Courtesy of GENERAL MOTORS CORP.
