Diagnostic Aids
WARNING: This page is about a different car, the 2003 GMC Sierra, 2003 GMC Cab & Chassis Sierra, 2003 Chevrolet Silverado, and 2003 Chevrolet Cab & Chassis Silverado. However, it is still accessible from the selected car via links, so may be relevant.
Use the Freeze Frame/Failure Records data in order to locate an intermittent condition. If you cannot duplicate the DTC, the information included in the Freeze Frame/Failure Records data may help in determining the number of miles since the DTC set. The Fail Counter and Pass Counter can also help in determining the number of ignition cycles that the diagnostic test reported a pass and/or fail. Operate the vehicle within the same Freeze Frame conditions, including those for RPM, for engine load, for vehicle speed, for temperature, and for others. This will isolate at what point the DTC failed. Refer to TESTING FOR INTERMITTENT AND POOR CONNECTIONS .
