Removal Procedure

WARNING: This page is about a different car, the 2003 GMC Sierra, 2003 GMC Cab & Chassis Sierra, 2003 Chevrolet Silverado, and 2003 Chevrolet Cab & Chassis Silverado. However, it is still accessible from the selected car via links, so may be relevant.
  1. Drain the engine oil.
  2. Remove the oil pan cover bolts (1), cover (2), and gasket (3).
  3. Discard the gasket.
    Fig 1: Removing Oil Pan Cover, Bolts, & Gasket
    G02106739Courtesy of GENERAL MOTORS CORP.
