Removal Procedure

WARNING: This page is about a different car, the 2003 GMC Sierra, 2003 GMC Cab & Chassis Sierra, 2003 Chevrolet Silverado, and 2003 Chevrolet Cab & Chassis Silverado. However, it is still accessible from the selected car via links, so may be relevant.
IMPORTANT: When performing the following procedures, use only hand tools to remove and install the drain and fill plugs.
  1. Raise and suitably support the vehicle. Refer to JACKING AND LIFTING .
  2. Remove the transfer case shield, if equipped. Refer to Transfer Case Shield Replacement .
  3. Remove the fill plug.
    Fig 1: Fill Plug
    G01481128Courtesy of GENERAL MOTORS CORP.
  4. Remove the drain plug.
    Fig 2: Drain Plug
    G01481129Courtesy of GENERAL MOTORS CORP.
