Installation Procedure

WARNING: This page is about a different car, the 2003 GMC Sierra, 2003 GMC Cab & Chassis Sierra, 2003 Chevrolet Silverado, and 2003 Chevrolet Cab & Chassis Silverado. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the seal to the vehicle.
    NOTE: Refer to FASTENER NOTICE .
  2. Install the nuts to the studs.

    Tighten

    Tighten the nuts to 3 N.m (25 lb in).

  3. Install the intermediate shaft. Refer to Intermediate Steering Shaft Replacement - Lower
    Fig 1: Install Steering Column Seal Nuts From Studs
    G01479823Courtesy of GENERAL MOTORS CORP.
