Removal Procedure

WARNING: This page is about a different car, the 2003 GMC Sierra, 2003 GMC Cab & Chassis Sierra, 2003 Chevrolet Silverado, and 2003 Chevrolet Cab & Chassis Silverado. However, it is still accessible from the selected car via links, so may be relevant.
NOTE: Refer to POWER STEERING HOSE DISCONNECTED NOTICE .
  1. Install a drain pan under the vehicle.
  2. Remove the brake booster inlet hose (1) from the brake booster (2).
  3. Remove the brake booster inlet hose from the power steering pump.
  4. Remove the brake booster inlet hose from the vehicle.
Fig 1: Remove Brake Booster Inlet Hose From Brake Booster
G01479554Courtesy of GENERAL MOTORS CORP.
