High or Low Temperature Control Effort

WARNING: This page is about a different car, the 2003 GMC Sierra, 2003 GMC Cab & Chassis Sierra, 2003 Chevrolet Silverado, and 2003 Chevrolet Cab & Chassis Silverado. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: High Or Low Temperature Control Effort (Steps 1-8)
G01478960Courtesy of GENERAL MOTORS CORP.
Fig 2: High Or Low Temperature Control Effort (Steps 9-21)
G01478961Courtesy of GENERAL MOTORS CORP.
