Removal Procedure

WARNING: This page is about a different car, the 2003 Oldsmobile Bravada, 2003 GMC Envoy XL, 2003 GMC Envoy, and 2003 Chevrolet TrailBlazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the rear seat bracket trim cover.
  2. Remove the hydraulic jack from the jack stowage area, on the left side only.
  3. Position the seat cushion assembly in order to gain access to the 2 rear seat mounting nuts.
  4. Remove the 2 mounting nuts.
  5. Remove the seat cushion assembly from the vehicle.
    6. Fig 1: Rear Seat Bracket Trim Cover
    G01641874Courtesy of GENERAL MOTORS CORP.
