Installation Procedure

WARNING: This page is about a different car, the 2003 Oldsmobile Bravada, 2003 GMC Envoy XL, 2003 GMC Envoy, and 2003 Chevrolet TrailBlazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the trim to the tail lamp, ensuring that the retaining tabs are fully seated.
  2. Install the tail lamp assembly to the vehicle. Refer to TAIL LAMP REPLACEMENT  in Lighting Systems.
    Fig 1: Installing Trim To Tail Lamp
    G01641153Courtesy of GENERAL MOTORS CORP.
