Diagnostic Aids
WARNING: This page is about a different car, the 2003 Oldsmobile Bravada, 2003 GMC Envoy XL, 2003 GMC Envoy, and 2003 Chevrolet TrailBlazer. However, it is still accessible from the selected car via links, so may be relevant.
- Use the Freeze Frame and/or Failure Records data in order to locate an intermittent condition. If you cannot duplicate the DTC, the information included in the Freeze Frame and/or Failure Records data may aid in determining the number of miles since the DTC set. The Fail Counter and Pass Counter can also aid in determining the number of ignition cycles that the diagnostic reported a pass and/or fail. Operate the vehicle within the same Freeze Frame conditions (RPM, engine load, vehicle speed, temperature, etc.). This will isolate when the DTC failed.
- Refer to TESTING WIRING SYSTEMS FOR INTERMITTENT & POOR CONNECTIONS in Wiring Systems.
