Removal Procedure

WARNING: This page is about a different car, the 2003 Oldsmobile Bravada, 2003 GMC Envoy XL, 2003 GMC Envoy, and 2003 Chevrolet TrailBlazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the air cleaner element. Refer to Air Cleaner Element Replacement   in Engine Controls-4.2L.
  2. Remove the air cleaner/washer container assembly. Refer to Air Cleaner Assembly Replacement   in Engine Controls-4.2L.
  3. Remove the washer pumps from the container assembly. Refer to WASHER PUMP REPLACEMENT (HEADLAMPS)   or WASHER PUMP REPLACEMENT (WINDSHIELD)   and WASHER PUMP REPLACEMENT - REAR   .
    Fig 1: Removing Washer Pumps From Container Assembly
    G01640604Courtesy of GENERAL MOTORS CORP.
