Removal Procedure

WARNING: This page is about a different car, the 2003 Oldsmobile Bravada, 2003 GMC Envoy XL, 2003 GMC Envoy, and 2003 Chevrolet TrailBlazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the washer solvent container. Refer to WASHER SOLVENT CONTAINER REPLACEMENT   .
  2. Disconnect the washer hose (4) from the pump (5).
  3. Remove the pump (5) from the solvent container by carefully pulling pump from the retainer (1).
  4. Remove the pump from the sealing grommet (3) by pulling the pump upwards.
    Fig 1: Removing Pump From Sealing Grommet
    G01640636Courtesy of GENERAL MOTORS CORP.
