Installation Procedure

WARNING: This page is about a different car, the 2003 Oldsmobile Bravada, 2003 GMC Envoy XL, 2003 GMC Envoy, and 2003 Chevrolet TrailBlazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the pump (2) to the sealing grommet (3).
  2. Install the pump (2) to the retainer (1) on the solvent container.
  3. Connect the washer hose (4) to the pump (2).
  4. Install the washer solvent container. Refer to WASHER SOLVENT CONTAINER REPLACEMENT   .
    Fig 1: Installing Pump To Retainer On Solvent Container
    G01640609Courtesy of GENERAL MOTORS CORP.
