Removal Procedure

WARNING: This page is about a different car, the 2003 Oldsmobile Bravada, 2003 GMC Envoy XL, 2003 GMC Envoy, and 2003 Chevrolet TrailBlazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Disconnect the washer nozzle (1) from the rear wiper arm.
  2. Remove the nozzle from the washer hose.
    Fig 1: Removing Nozzle From Washer Hose
    G01640642Courtesy of GENERAL MOTORS CORP.
