Removal Procedure

WARNING: This page is about a different car, the 2003 Oldsmobile Bravada, 2003 GMC Envoy XL, 2003 GMC Envoy, and 2003 Chevrolet TrailBlazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Open the hood.
  2. Remove the headlamp. Refer to HEADLAMP BULB REPLACEMENT   .
  3. Rotate the bulb and socket counterclockwise in order to remove the bulb and socket from the housing.
  4. Remove the side marker bulb (3) or turn signal/park bulb (4) from the socket.
    Fig 1: Removing Side Marker Bulb & Turn Signal/Park Bulb From Socket
    G01640515Courtesy of GENERAL MOTORS CORP.
