Removal Procedure

WARNING: This page is about a different car, the 2003 Oldsmobile Bravada, 2003 GMC Envoy XL, 2003 GMC Envoy, and 2003 Chevrolet TrailBlazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the left closeout/insulator panel. Refer to CLOSEOUT/INSULATOR PANEL REPLACEMENT - LEFT  in Instrument Panel, Gages and Console.
  2. Remove the flasher retaining bracket from the insulator panel.
  3. Disconnect the flasher from the electrical connector.
  4. Remove the flasher from the vehicle.
    Fig 1: Removing Flasher From Vehicle
    G01640479Courtesy of GENERAL MOTORS CORP.
