Installation Procedure

WARNING: This page is about a different car, the 2003 Oldsmobile Bravada, 2003 GMC Envoy XL, 2003 GMC Envoy, and 2003 Chevrolet TrailBlazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the back up lamp to the fascia.
    NOTE: Refer to FASTENER NOTICE in Cautions and Notices.
  2. Install the 2 backup lamp retaining nuts.

    Tighten

    Tighten the nuts to 10.0 N.m (88 lb in).

  3. Install the backup lamp socket.
    Fig 1: Installing Back Up Lamp & Nuts To Fascia
    G01640534Courtesy of GENERAL MOTORS CORP.
