Special Tools

WARNING: This page is about a different car, the 2004 Chevrolet Corvette. However, it is still accessible from the selected car via links, so may be relevant.

Special Tools

Illustration	Tool Number/Description
Courtesy of GENERAL MOTORS CORP.	J 8001 Dial Indicator Set
Courtesy of GENERAL MOTORS CORP.	J 23907 Slide Hammer
Courtesy of GENERAL MOTORS CORP.	J 25070 Heat Gun
Courtesy of GENERAL MOTORS CORP.	J 29369-2 Bushing and Bearing Remover - 2-3 in
Courtesy of GENERAL MOTORS CORP.	J 36221 Hydraulic Line Clutch Separator
Courtesy of GENERAL MOTORS CORP.	J 42055 Transmission Support Fixture
Courtesy of GENERAL MOTORS CORP.	J 42155 Differential Lifting Tool
Courtesy of GENERAL MOTORS CORP.	J 42157 Left Output Shaft Bearing Installer
Courtesy of GENERAL MOTORS CORP.	J 42159 Differential Side Bearing Remover
Courtesy of GENERAL MOTORS CORP.	J 42162 Side Gear Compressor
Courtesy of GENERAL MOTORS CORP.	J 42164 Pinion Gear Holder
Courtesy of GENERAL MOTORS CORP.	J 42166 Front Pinion Bearing Remover
Courtesy of GENERAL MOTORS CORP.	J 42168-1 Differential Centerline Cylinder
Courtesy of GENERAL MOTORS CORP.	J 42168-11 Pinion Housing Centering Spacer
Courtesy of GENERAL MOTORS CORP.	J 42168-13 Gage Plate Assembly
Courtesy of GENERAL MOTORS CORP.	J 42168-15 Side Bearing Shim Selector
Courtesy of GENERAL MOTORS CORP.	J 42168-16 Spacers
Courtesy of GENERAL MOTORS CORP.	J 42168-2 Shim Gage Assembly
Courtesy of GENERAL MOTORS CORP.	J 42168-7 Depth Gage
Courtesy of GENERAL MOTORS CORP.	J 42168-9 Holding Strap
Courtesy of GENERAL MOTORS CORP.	J 42170 Bearing and Race Installer
Courtesy of GENERAL MOTORS CORP.	J 42172 Bearing Race Installer/Spanner Wrench
Courtesy of GENERAL MOTORS CORP.	J 42173 Differential Holding Fixture
Courtesy of GENERAL MOTORS CORP.	J 42194 Bearing Race Remover
Courtesy of GENERAL MOTORS CORP.	J 46405 Output Shaft Seal Installer
