Manual Transmission

WARNING: This page is about a different car, the 2004 Chevrolet Corvette. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: 4L60-E Transmission VIN Derivative Location Component View M30

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
1	VIN Derivative, Primary Location
2	VIN Derivative, Secondary Location

The 6-speed manual transmission, the Borg Warner Modified T-56 (RPO MM6), is stamped with a VIN derivative, which will be located in either the primary or secondary location, as shown. For additional information, refer to VIN Derivative .
